Now i haven't used their diamond pastes yet (still have a rather large stock of the other ones), but some time ago i did buy a packet of coarser grit diamond powder from them, and so far this performs most excellent as a replacement for the standard SiC grit on a Paper Wheel.
Very useful for initial edges on especially high vanadium carbide rich steel types.
This type of strop is what i sometimes make & give to people who regularly bring me a CRK or other quality (Chef-) knife for sharpening and/or some TLC, so they can maintain & keep the appearance of their new edge themselves for some time.
Even a few professional Chefs in my area with expensive gyuto's and santoku's in modern PM steel types are using these same strops with good results, so they keep telling me anyway.
I use them myself as well, and they are easy to make.
What you see is a new & cut-to-size piece of clean MDF (medium density fiberboard) coated with a thin layer of 1.0 micron (~ 14000 grit) mono-diamond compound, and i put 4 self-adhesive rubber bumpers on the bottom.
These make the strop non-slip plus they elevate the working surface a bit more which makes the strop more convenient to use on a table (more room for your hands)
Due to the harder surface the chances of rounding your crisp apex are also greatly diminished when compared to stropping on compressible materials like leather.
The strop surface can also be cleaned from time to time with a microfiber cloth and some acetone, which will remove all or most of the swarf without removing the diamond particles, as these become (partially) embedded in the MDF surface during the stropping proces.
But this is (literally) the key element: the placement on rubber bumpers also provides the strop user with acoustic feedback by isolating the MDF from the table (a bit like the bars on a xylophone); you can actually hear when you're arriving at the very apex during stropping movements as the audible sound changes, which makes the stropping proces very easy, even for absolute beginners.
The CRK Nyala used as a prop for the pictures was reprofiled (from 35-40 degrees inclusive to an even 30 degrees inclusive) & sharpened (with 15 micron diamond compound on a Paper Wheel).
The owner only uses this quite expensive knife to cut oranges, about 5 each day, i kid you not.
The owner of this Sebenza 25 personally checked out several of this model at the dealer (Knivesandtools NL), and all of these Sebenza's had worse edges than the one he finally bought, but he already knew someone who could fix that.
And i've had quite a few more brand new CRK's come in this way (with overly large edge angles and/or completely blunt.
For several years now Knivesandtools send unhappy CRK customers to me, which is nice, but of course shouldn't be necessary with a brand new knife, especially a CRK which always comes with a card stating that the knife is very sharp.
The owner of this Sebenza 25 bought the knife brand new through an official dealer in the Netherlands, but although he was and is still very pleased with the knife itself, he soon found that the factory edge didn't cut too well.
He tried to improve things with the help of a Spyderco Sharpmaker and a leather strop loaded with some green compound, but to no avail.
So he sent the knife to me, and the first thing i did was to measure the edge angle.
According to my Tormek Angle Gauge it measured 50 degrees inclusive on the straight part of the edge, going up to 55 degrees inclusive from the belly to the point.(!)
This is how the knife looked before sharpening:
First i removed the apex of the old edge by cutting a few times lightly into an old silicon carbide stone, after which i reprofiled it freehand on my Tormek SB-250 Blackstone to an even 30 degrees inclusive.
This was followed by a Paper Wheel with 220 grit SiC to smoothen the grindlines made by the Tormek, then refined with a second Paper Wheel coated with 15 micron diamond compound, and finally removed the burr with a third Paper Wheel coated with 0.25 diamond compound. (this leaves the 15 micron scratch pattern intact as much as possible to preserve bite)
The resulting edge treetops the hair on the back of my hand, can slice single-ply toilet paper, and survives a few cuts into my laminated testblock without any visible damage (checked under bright light with the loupe in my Victorinox SwissChamp)
A niece of mine is an avid amateur Chef (but not yet a knife afi), and this black ceramic knife (a rebranded Kyocera) is one of her favorites in the kitchen, as due to the tougher blade material the edges can be made thinner and thus the knife cuts better than a white ceramic version. Longtime use however (not always on a suitable cutting board) plus storing it unprotected in a drawer between a bunch of steel bladed knives had blunted the edge to a point next to unusable, complete with quite a lot of (micro) chips and a broken tip.
This is the knife as it was when i received it. (when you click the pictures 2 x you can see the chips clearly)
This is the knife after sharpening. I reprofiled the rather bad factory edge to an ever so slight convex edge of +/- 25 degrees inclusive, and the sharpness is just hairwhittling (only towards the root, not to the point) It easily slices single layer toiletpaper (torn apart 3-layered version) and a tomato of course. Removing the chips and setting the new bevel was done with a Tormek T7, refining & convexing with a Paper Wheel coated with 15 micron diamond compound, and semi-polishing with a second Paper Wheel coated with 6 micron diamond compound.
Specs:
Overall length: 11.0 inch (28,0 cm) Blade length: 5.8 inch (14,8 cm) Blade thickness: 1,84 mm Blade type: black ceramic / saber-hollow Thickness behind the edge: 0,4 mm
The first clip shows the slicing of a piece of standard 3-layered toilet paper, for the second clip i peel off 1 layer and slice the remaining 2 layers, and the third clip shows the slicing of just the remaining single layer of toilet paper:
Inhalte von externen Seiten werden ohne Ihre Zustimmung nicht automatisch geladen und angezeigt.
Durch die Aktivierung der externen Inhalte erklären Sie sich damit einverstanden, dass personenbezogene Daten an Drittplattformen übermittelt werden. Mehr Informationen dazu haben wir in unserer Datenschutzerklärung zur Verfügung gestellt.
Inhalte von externen Seiten werden ohne Ihre Zustimmung nicht automatisch geladen und angezeigt.
Durch die Aktivierung der externen Inhalte erklären Sie sich damit einverstanden, dass personenbezogene Daten an Drittplattformen übermittelt werden. Mehr Informationen dazu haben wir in unserer Datenschutzerklärung zur Verfügung gestellt.
Inhalte von externen Seiten werden ohne Ihre Zustimmung nicht automatisch geladen und angezeigt.
Durch die Aktivierung der externen Inhalte erklären Sie sich damit einverstanden, dass personenbezogene Daten an Drittplattformen übermittelt werden. Mehr Informationen dazu haben wir in unserer Datenschutzerklärung zur Verfügung gestellt.
Inhalte von externen Seiten werden ohne Ihre Zustimmung nicht automatisch geladen und angezeigt.
Durch die Aktivierung der externen Inhalte erklären Sie sich damit einverstanden, dass personenbezogene Daten an Drittplattformen übermittelt werden. Mehr Informationen dazu haben wir in unserer Datenschutzerklärung zur Verfügung gestellt.
A small black ceramic backlock folder without any markings (Böker ?) i did in 2013.
This well made knife had practically no edge and no point to speak of when i received it, and even opening mail with it was difficult.
I used the Tormek Blackstone graded to around 1000 grit for freehand reprofiling, followed by 3 Paper Wheels coated with 15, 6.0 and 3.0 micron diamond compounds for refining & polishing.
The new edge fits in the 30 degrees inclusive slot on my Tormek angle gauge, is slightly convex, and can shave the hair on my leg in both directions.
Microtech custom Ultratech VIII Double Action OTF with stainless steel handle & blued carbon steel Damascus dagger blade from 09/2008 with serial number 001.
Handle material: hot gun blued steel with 59 inches of 24 kt gold wire inlays plus a 2,0 mm sapphire in the firing button
Weight: 157 grams
Comes in padded pouch
(specks in some of the pics are dust particles in reality)
